Available for Quotation
Out of stock
Out of stock
This is a 350A circuit breaker for EasyPact EZC400N. This product can work below rated operational voltage(Ue) 440VAC at 50/60Hz. The ultimate breaking capacity(Icu) is 50kA at 440V in terms of complete range Ics=100%Icu(Ics= 50%Icu at 440V. This version of product is designed 3 poles frame with detection on 3 poles equiped TMD trip unit for thermal-magnetic protection. It is compliance with standard IEC60947 CE certification and some independent lab(KEMA ASEFA TUV) or third-party Tilva. This device is certified for operation in pollution degree III environment as defined by IEC60947 and pass the test of extremely atmospheric conditions. Device can be mounted vertically or horizontally in a metal enclosure and against from safety risk by padlocking. The degree of protection is IP40 for direct rotary handle and IP54 for extended rotary handle. This series have slots used for indication or voltage release auxiliaries positioning depending on where it is inserted in the device behind the front cover of circuit breaker. The fixed dimension is 140mm(width) 255mm(height) 110mm(Depth).
circuit breaker Easypact EZC400N – TMD – 350 A – 3 poles 3d
| Weight | 4.937 kg |
|---|---|
| Dimensions | 29 × 16 × 15 mm |
| Product group | |
| Brand | |
| GTIN_EAN_13 code | |
| GTIN_EAN_14 code |
No downloads available for this product.
| 5 star | 0% | |
| 4 star | 0% | |
| 3 star | 0% | |
| 2 star | 0% | |
| 1 star | 0% |
Sorry, no reviews match your current selections
